UPS MODEL |
|
HL-3C20KS |
|
|
|
|
Rated capacity |
20KVA/16KW |
|
|
|
INPUT |
|
|
|
|
|
|
Wire method |
Single phrase or three phase earth ground |
Rated voltage |
380VAC |
|
Normal Voltage |
120VAC - 275VAC ±5 |
Rated Freq |
50HZ |
Frequency Range |
(45- 55)HZ±0.5HZ |
Bypass range |
187VAC-264VAC |
BAT |
|
|
|
|
|
|
Rated bat Voltage |
192VDC |
Battery capacity*Quantily |
12VDC*16PCS |
|
AC OUTPUT |
|
|
|
|
|
|
Output system |
Single phrase & earth ground |
OutPut voltage |
220VAC±3% |
Output frequency |
50HZ±1% |
Dynamic voltage transient range |
<5% |
Dynamic transient restore |
<60ms |
Waveform |
Sine ware THD<3%(linear load) Sine ware TDH<8%(nonlinear load) |
Input power factor |
0.8 |
Overload capability |
105%-125% 30s to Bypass |
Communications |
RS232(turn to 485), Intelligelt slot |
Net weight |
|
|
|
|
|
|
Dimensions |
248*500*616mm |
|
Environmental |
|
|
|
|
|
|
Ambient temperature |
10ᵒC - +40ᵒC |
Altiude |
Lower than 1000m: no derating Over 1000m: 1% derating for every 100m rise |
Storage temperature |
15ᵒC - + 45ᵒC |
|
|
|
|
|
|
|
HL -UPS ONLINE TỪ 6KVA - 20KVA ĐƯỢC BẢO HÀNH 36 THÁNG CHO BỘ XỬ LÝ VÀ 24 THÁNG CHO ẮC QUY |
